TBTDAT-II
TBTSCIETECH
| Availability: | |
|---|---|
The Micro Deval apparatus is a specialized device used for the Micro Deval abrasion test, an essential procedure for assessing the durability of aggregates. This Micro Deval machine evaluates how well aggregates resist abrasion and degradation under simulated wear conditions. Often referred to simply as the Micro Deval test or Micro Deval, this test provides crucial data on the aggregate’s performance, ensuring that it meets the required standards for construction applications. By accurately measuring the abrasion resistance, the Micro Deval apparatus helps ensure the long-term quality and stability of road and construction materials.
For some stone aggregates, the abrasion strength are different depend on in state of dry or moist. This Deval machine is used to measure specific abrasion strength of aggregates, then to determine the quality of it.
The machine mainly consists of 4 rolling cylinder tanks, sealing covers, holding frame, gearbox, motor and controller.
Related Standard: NF P18-572.
The Micro Deval apparatus is a specialized device used for the Micro Deval abrasion test, an essential procedure for assessing the durability of aggregates. This Micro Deval machine evaluates how well aggregates resist abrasion and degradation under simulated wear conditions. Often referred to simply as the Micro Deval test or Micro Deval, this test provides crucial data on the aggregate’s performance, ensuring that it meets the required standards for construction applications. By accurately measuring the abrasion resistance, the Micro Deval apparatus helps ensure the long-term quality and stability of road and construction materials.
For some stone aggregates, the abrasion strength are different depend on in state of dry or moist. This Deval machine is used to measure specific abrasion strength of aggregates, then to determine the quality of it.
The machine mainly consists of 4 rolling cylinder tanks, sealing covers, holding frame, gearbox, motor and controller.
Related Standard: NF P18-572.
The 4 cylinder tanks are mounted on two horizontal axis. Each cylinder can be used for one test.
The cylinder tanks are made of stainless-steel (Z 2 CN 18-10).
Inside the cylinder, there should not be any uneven due to welding.
The milling balls which to be put in cylinder and rolling with specimen, are made of stainless steel Z 30 C 13 of diameter 10±0.5mm.
Electric motor drives the cylinders rotating at a constant speed of 100±5 tr/min to perform abrasion testing. The engine will be automatically stopped at end of the test.
The 4 cylinder tanks are mounted on two horizontal axis. Each cylinder can be used for one test.
The cylinder tanks are made of stainless-steel (Z 2 CN 18-10).
Inside the cylinder, there should not be any uneven due to welding.
The milling balls which to be put in cylinder and rolling with specimen, are made of stainless steel Z 30 C 13 of diameter 10±0.5mm.
Electric motor drives the cylinders rotating at a constant speed of 100±5 tr/min to perform abrasion testing. The engine will be automatically stopped at end of the test.
Milling Cylinders | 4 pcs |
Cylinder inner diameter | 200±1mm for particle 4~14mm |
400±2mm for particle 20~50mm | |
Cylinder length | 154±1mm |
Cylinder wall thickness | 3~4mm |
Caps for cylinders | 8mm thickness for sealing |
Steel balls | diameter 10mm, 4kg |
Voltage | 220V, power 1KW |
Power consumption | 1KW |
Milling Cylinders | 4 pcs |
Cylinder inner diameter | 200±1mm for particle 4~14mm |
400±2mm for particle 20~50mm | |
Cylinder length | 154±1mm |
Cylinder wall thickness | 3~4mm |
Caps for cylinders | 8mm thickness for sealing |
Steel balls | diameter 10mm, 4kg |
Voltage | 220V, power 1KW |
Power consumption | 1KW |
