TBTUTM-A Series (WEW-1000B)
TBTSCIETECH
| TBTUTM-100A: | |
|---|---|
| TBTUTM-300A: | |
| TBTUTM-600A: | |
| TBTUTM-1000A: | |
| Availability: | |
Computerized hardness Digital Universal testing machine is mainly designed for the tensile test, compression test and bending test of metal, also for non-metal of compression test, such as concrete and stone. If the proper jigs are provided, it can be used for various tests in the laboratories of mills, factories, colleges and research units concerned.
It is featured with hydraulic loading, electronic force measurement, the load, the test process with curve can be displayed on the computer screen, and the data can be saved and printed out. It is overload protection. The oil cylinder is fitted on the bottom of the main frame, which is suitable for the compression test and all the annex will be provided for the technological tests of the metal.
The Computerized Hardness Digital Universal Testing Machine by Nanjing T-Bota SciTech Instruments & Equipment Co., Ltd. is a highly advanced and precise testing device designed to measure the hardness of materials in a wide range of applications. It is equipped with cutting-edge technology and features a digital display for easy reading and efficient operation. This machine is ideal for testing materials such as metals, plastics, and composites, ensuring that they meet the required standards for quality and performance.
Engineered for both simplicity and accuracy, this universal testing machine allows users to perform various tests including hardness tests, tensile tests, and compression tests, providing valuable data for materials science, quality control, and product development. Whether used in laboratories or industrial settings, this system offers precision and versatility, ensuring reliable results across different testing scenarios.
Computerized hardness Digital Universal testing machine is mainly designed for the tensile test, compression test and bending test of metal, also for non-metal of compression test, such as concrete and stone. If the proper jigs are provided, it can be used for various tests in the laboratories of mills, factories, colleges and research units concerned.
It is featured with hydraulic loading, electronic force measurement, the load, the test process with curve can be displayed on the computer screen, and the data can be saved and printed out. It is overload protection. The oil cylinder is fitted on the bottom of the main frame, which is suitable for the compression test and all the annex will be provided for the technological tests of the metal.
The Computerized Hardness Digital Universal Testing Machine by Nanjing T-Bota SciTech Instruments & Equipment Co., Ltd. is a highly advanced and precise testing device designed to measure the hardness of materials in a wide range of applications. It is equipped with cutting-edge technology and features a digital display for easy reading and efficient operation. This machine is ideal for testing materials such as metals, plastics, and composites, ensuring that they meet the required standards for quality and performance.
Engineered for both simplicity and accuracy, this universal testing machine allows users to perform various tests including hardness tests, tensile tests, and compression tests, providing valuable data for materials science, quality control, and product development. Whether used in laboratories or industrial settings, this system offers precision and versatility, ensuring reliable results across different testing scenarios.
1. Hydraulic system are equipped with high quality hydraulic components, to ensure machine long-term & stable operation.
2. Machine equipped with protection for overload and limit, safe and reliable.
3. Between upper and lower platen is the tensile space; Between lower platen and platform is the compression space.
4. Testing curve and data can be displayed directly on computer.
High Accuracy and Precision The Computerized Hardness Digital Universal Testing Machine offers high accuracy and repeatability in hardness testing. Its digital measurement system ensures precise results for various materials, from soft plastics to hardened metals, with minimal margin of error.
Wide Testing Range This machine covers a wide range of hardness scales, including Rockwell, Brinell, Vickers, and others, allowing it to test materials of various hardness levels with ease. Its adaptability makes it a versatile tool for industries involved in material science, manufacturing, and product development.
Computerized Control System Featuring an integrated computerized control system, this machine offers automated testing and data recording, making the testing process more efficient. The computer control system ensures precise force application and accurate data capture, streamlining the testing process.
User-Friendly Interface The Computerized Hardness Digital Universal Testing Machine comes with a digital display and an intuitive interface, making it easy to use for both experienced professionals and beginners. The clear and easy-to-read digital interface allows users to quickly interpret test results and adjust settings as necessary.
Advanced Testing Software The testing machine comes with built-in advanced software that allows for real-time monitoring of testing procedures, data analysis, and result recording. The software supports comprehensive test reports and can store a vast amount of testing data for future reference or analysis.
Robust Build and Durability Constructed with high-quality materials, this machine is built to last and withstand rigorous testing environments. Whether used in a research laboratory or an industrial setting, the Computerized Hardness Digital Universal Testing Machine offers excellent reliability and durability.
Automatic Data Recording and Reporting The system automatically records and stores the testing data for easy access and comparison. This feature is particularly beneficial for quality control and documentation purposes in both academic and industrial applications.
1. Hydraulic system are equipped with high quality hydraulic components, to ensure machine long-term & stable operation.
2. Machine equipped with protection for overload and limit, safe and reliable.
3. Between upper and lower platen is the tensile space; Between lower platen and platform is the compression space.
4. Testing curve and data can be displayed directly on computer.
High Accuracy and Precision The Computerized Hardness Digital Universal Testing Machine offers high accuracy and repeatability in hardness testing. Its digital measurement system ensures precise results for various materials, from soft plastics to hardened metals, with minimal margin of error.
Wide Testing Range This machine covers a wide range of hardness scales, including Rockwell, Brinell, Vickers, and others, allowing it to test materials of various hardness levels with ease. Its adaptability makes it a versatile tool for industries involved in material science, manufacturing, and product development.
Computerized Control System Featuring an integrated computerized control system, this machine offers automated testing and data recording, making the testing process more efficient. The computer control system ensures precise force application and accurate data capture, streamlining the testing process.
User-Friendly Interface The Computerized Hardness Digital Universal Testing Machine comes with a digital display and an intuitive interface, making it easy to use for both experienced professionals and beginners. The clear and easy-to-read digital interface allows users to quickly interpret test results and adjust settings as necessary.
Advanced Testing Software The testing machine comes with built-in advanced software that allows for real-time monitoring of testing procedures, data analysis, and result recording. The software supports comprehensive test reports and can store a vast amount of testing data for future reference or analysis.
Robust Build and Durability Constructed with high-quality materials, this machine is built to last and withstand rigorous testing environments. Whether used in a research laboratory or an industrial setting, the Computerized Hardness Digital Universal Testing Machine offers excellent reliability and durability.
Automatic Data Recording and Reporting The system automatically records and stores the testing data for easy access and comparison. This feature is particularly beneficial for quality control and documentation purposes in both academic and industrial applications.
Model | TBTUTM-100A | TBTUTM-300A | TBTUTM-600A | TBTUTM-1000A |
Max. capacity（KN) | 100 | 300 | 600 | 1000 |
Range | 4%-100%F.S.(full range, without gear） | |||
Reading accuracy | Grade 1 | |||
Error | ±1% | |||
Resolution (F.S.) | 1/200000F.S. | |||
Column Number | 4 | 4 | 4 | 6 |
Width between two column | 345 | 430 | 515 | 510 |
Max tensile space（mm) | 500 | 600 | 600 | 600 |
Max compression space(mm) | 500 | 600 | 600 | 600 |
Bending test Distance between two points (mm) | 100-270 | 100-350 | 100-400 | 100-400 |
Round specimen clamp diameter(mm) | Ø6-Ø22 | Ø10-Ø32 | Ø13-Ø40 | Ø20-Ø40 |
Flat specimen clamp thickness (mm) | 0-15 | 0-15 | 0-15 | 0-40 |
Stroke (mm) | 150 | 200 | ||
Pistons rise fastest speed(mm/min） | 100 | 80 | ||
Beam rising speed (mm/min) | 310 | 250 | 250 | 310 |
Displacement reading relative error | ±1% | |||
Deformation reading relative error | ±1% | |||
Motor capacity (KW) | 2 | 2.5 | ||
Main unit dimension (mm) | 665×490×1600 | 740×460×1900 | 850×560×2000 | 960×620×2100 |
Oil source cabinet dimension (mm) | 1000×600×910 | |||
Main unit net weight (kg) | 600 | 1200 | 1750 | 2200 |
Oil source cabinet net weight（kg) | 250 | |||
Remark:
1. working temperature: 10~35C
2. Relative humidity: less than 80%
3. Power supply: 220VAC or 380VAC
4. Machine should be placed in a clean place, away from vibration, corrosion and magnetic field.
At Nanjing T-Bota SciTech Instruments & Equipment Co., Ltd., we understand that quality service is critical to maintaining the performance and longevity of your testing equipment. We offer a range of services to ensure you get the most out of your Computerized Hardness Digital Universal Testing Machine:
Technical Support – Our team of experts is available to assist with any technical issues, from setup to troubleshooting. We offer both on-site and remote support to ensure your machine operates smoothly.
Training – We provide training sessions for your team to ensure efficient operation and maintenance of the system. Training includes software usage, machine calibration, and testing procedures.
Routine Maintenance – To ensure the longevity of the machine, we offer routine maintenance packages, which include calibration, cleaning, and software updates.
Repairs and Replacements – In case of any malfunction, we provide fast repair services, ensuring minimal downtime. Our spare parts inventory is stocked with high-quality components to replace any worn or damaged parts.
Model | TBTUTM-100A | TBTUTM-300A | TBTUTM-600A | TBTUTM-1000A |
Max. capacity（KN) | 100 | 300 | 600 | 1000 |
Range | 4%-100%F.S.(full range, without gear） | |||
Reading accuracy | Grade 1 | |||
Error | ±1% | |||
Resolution (F.S.) | 1/200000F.S. | |||
Column Number | 4 | 4 | 4 | 6 |
Width between two column | 345 | 430 | 515 | 510 |
Max tensile space（mm) | 500 | 600 | 600 | 600 |
Max compression space(mm) | 500 | 600 | 600 | 600 |
Bending test Distance between two points (mm) | 100-270 | 100-350 | 100-400 | 100-400 |
Round specimen clamp diameter(mm) | Ø6-Ø22 | Ø10-Ø32 | Ø13-Ø40 | Ø20-Ø40 |
Flat specimen clamp thickness (mm) | 0-15 | 0-15 | 0-15 | 0-40 |
Stroke (mm) | 150 | 200 | ||
Pistons rise fastest speed(mm/min） | 100 | 80 | ||
Beam rising speed (mm/min) | 310 | 250 | 250 | 310 |
Displacement reading relative error | ±1% | |||
Deformation reading relative error | ±1% | |||
Motor capacity (KW) | 2 | 2.5 | ||
Main unit dimension (mm) | 665×490×1600 | 740×460×1900 | 850×560×2000 | 960×620×2100 |
Oil source cabinet dimension (mm) | 1000×600×910 | |||
Main unit net weight (kg) | 600 | 1200 | 1750 | 2200 |
Oil source cabinet net weight（kg) | 250 | |||
Remark:
1. working temperature: 10~35C
2. Relative humidity: less than 80%
3. Power supply: 220VAC or 380VAC
4. Machine should be placed in a clean place, away from vibration, corrosion and magnetic field.
At Nanjing T-Bota SciTech Instruments & Equipment Co., Ltd., we understand that quality service is critical to maintaining the performance and longevity of your testing equipment. We offer a range of services to ensure you get the most out of your Computerized Hardness Digital Universal Testing Machine:
Technical Support – Our team of experts is available to assist with any technical issues, from setup to troubleshooting. We offer both on-site and remote support to ensure your machine operates smoothly.
Training – We provide training sessions for your team to ensure efficient operation and maintenance of the system. Training includes software usage, machine calibration, and testing procedures.
Routine Maintenance – To ensure the longevity of the machine, we offer routine maintenance packages, which include calibration, cleaning, and software updates.
Repairs and Replacements – In case of any malfunction, we provide fast repair services, ensuring minimal downtime. Our spare parts inventory is stocked with high-quality components to replace any worn or damaged parts.
Standard Packing list
A-1. Main Unit
A-2. Control Cabinet
A-3. Computer, printer
A-4. Operation manual, certificate of calibration
A-5. Accessories pack
A-5 Accessories pack
a. Jaw for round specimen D20~40/D40~60mm (4pcs each size)
b. Jaw for plate specimen D-~40mm(4pcs)
c. Compression plate D150mm *1pc
d. Ball-shaped plate D150mm *1set
e. Bending test device (without bending punch)
f. Anchor bolt and nut M24 x 300mm*4sets
g. Oil tube (6AI-2.8m / 6AI-3.3m, 2pcs each size)
h. Hex wrench (4mm / 5mm*1pc each size)
i. Molybdenum disulfide lithium grease
j. O-ring
k. D50 cold bending punch (or pressure head)
The Computerized Hardness Digital Universal Testing Machine comes fully equipped for immediate use. The packing list includes:
Main Testing Machine Unit – The primary device with a digital LCD display for control and measurement.
Indenter Set – Includes multiple indenters (Rockwell, Brinell, Vickers) for various hardness tests.
Test Blocks – Reference hardness blocks for calibration and standardization.
Power Cord – Standard power supply cable for operation.
User Manual – Comprehensive guide for setup, operation, and maintenance.
Computerized Testing Software – Pre-installed software for automated testing and data analysis.
Warranty Card – Document confirming the one-year warranty for the product.
Standard Packing list
A-1. Main Unit
A-2. Control Cabinet
A-3. Computer, printer
A-4. Operation manual, certificate of calibration
A-5. Accessories pack
A-5 Accessories pack
a. Jaw for round specimen D20~40/D40~60mm (4pcs each size)
b. Jaw for plate specimen D-~40mm(4pcs)
c. Compression plate D150mm *1pc
d. Ball-shaped plate D150mm *1set
e. Bending test device (without bending punch)
f. Anchor bolt and nut M24 x 300mm*4sets
g. Oil tube (6AI-2.8m / 6AI-3.3m, 2pcs each size)
h. Hex wrench (4mm / 5mm*1pc each size)
i. Molybdenum disulfide lithium grease
j. O-ring
k. D50 cold bending punch (or pressure head)
The Computerized Hardness Digital Universal Testing Machine comes fully equipped for immediate use. The packing list includes:
Main Testing Machine Unit – The primary device with a digital LCD display for control and measurement.
Indenter Set – Includes multiple indenters (Rockwell, Brinell, Vickers) for various hardness tests.
Test Blocks – Reference hardness blocks for calibration and standardization.
Power Cord – Standard power supply cable for operation.
User Manual – Comprehensive guide for setup, operation, and maintenance.
Computerized Testing Software – Pre-installed software for automated testing and data analysis.
Warranty Card – Document confirming the one-year warranty for the product.
