Cleveland Open Cup Flash Point Tester
Product Description
1. It adopts special heating furnace to ensure the safety of test. The heating power is continuously adjustable. It can meet requirements of test.
2. The instrument adopts desktop structure. The stainless steel working table and furnace shell make it beautiful and elegant.
3. The instrument is fully self-contained complete. The operator can do determination as long as connecting with coal gas or other civil gas.
4. It equipped with flame extinguishing cover which accord with requirements of test
Specification
Power supply: | AC（220±10%）V, 50Hz. |
Heating device | Quartz tube furnace heating, no naked fire, explosion prevented. The power is adjustable from 0W to 600W. |
Test flame applicator | It applies the test flame automatically. |
Thermometer: | (-6～400)℃. It is the same as thermometer ASTM 11C. |
Igniting device | (1) Ignition source: coal gas(or civil gas) (2) Flame diameter is 3.2mm～4.8mm |
Ambient temperature: | (-10∼50)℃ |
Relative humidity | ≤85% |
Maximum power consumption | 650W |
Dimension | 350mm×290mm×350mm (thermometer is not included) |
Accessories
No. | Name | Unit | Qty | Remark |
1 | Main unit | Set | 1 | |
2 | Cleveland oil cup | Piece | 1 | We can provide more if you required. |
3 | Ignition device | Set | 1 | |
4 | Thermometer | Piece | 1 | -6℃～400 ℃, scale division is 2 ℃ |
5 | Thermometer holder | Set | 1 | |
6 | Fuse 5 A (Φ5×20) | Piece | 2 | |
7 | Latex tube Φ6 | Meter | 1.5 | Could not be used as coal gas tube |
8 | Joint for coal gas tube | Piece | 1 | Connect coal gas tube and latex tube |
9 | Extinguishing cover | Piece | 1 |
